SHIELD Solo Plus

Advanced Side-View X-Ray designed to inspect rigid containers (metal cans. composite cans, plastic containers).

Request details

Key Stats

X-Ray tube
600W metal ceramic
Metal detection size
0.8 mm SS
Glass detection size
1.5 mm SLG
Speed
High speed operation up to 233 m/minute
Optional
Filler/Seamer, Monitoring/Sampling

Typical Applications

Metal food cans
Metal beverage containers
PET containers

The Solo is specially designed for the inspection of non-glass rigid containers.

The SHIELD Solo Plus is part of InspX’s family of advanced side-view X-Ray inspection systems and is specially designed for the inspection of non-glass rigid containers (e.g. metal and composite cans, plastic containers and boxes).

The Solo Plus mounts over the customer’s existing conveyor and therefore offers completely non-contact inspection at linear speeds up to 233 meters (700 feet) or 2000 containers per minute!

The Solo Plus leverages InspX’s proprietary inspection software to detect a wide range of foreign material and container defects (e.g. knock down flanges).

Finally, the Solo is easy to own and inexpensive to maintain. Superior InspX service ensures that you’ll have access to immediate support 24X7 and convenient local service when you need it.

Tech Specs

Machine Architectures Side-view X-Ray system
Conveyor Mounts over customer’s existing conveyor. No transfer points, product contact
X-Ray Tube Configuration One metal ceramic tube – one X-Ray beam
Product/Package Size Width: 175mm (7 inches)

Height: 300mm (12 Inches)
Environment IP 65 (IP 69K optional)
Speed Up to 233 m/minute (700 ft/min)
Voltage

120 VAC, 30A, 50/60Hz single phase
Air 80psi @5cfm (for ejection only)
Ambient Temperature 1°C – 45°C
Diode Size 0.8mm standard, 0.4mm and 0.2mm software configurable
Container Ejection Full family of ejection options available
Dimensions (LxWxH) 889 x 1,727 x 1880 mm (35 x 68 x 74.1 in)

Features

Easy Installation

New industrial design allows for tool-less line installation with a streamlined machine footprint

Superior Inspection Performance

High-contrast metal ceramic tube coupled with our new high-resolution, low-noise detector module delivers superior inspection performance.

Best-in-Class Safety

Industry-leading Category 4, Performance Level E safety system provides redundancy on all critical safety functions for the most fault-tolerant design.

Modular Design

All subsystems have been redesigned with the highest reliability and uptime in mind. Servicing has never been easier.

Real-Time Support

Shield Solo includes wireless capabilities for 24/7 support by our global service team.

Options

Operations Guardian

Operations Guardian is a revolutionary monitoring system that offers a variety of advantages:

  • Real time system and performance monitoring of each machine
  • Proactive outreach from Peco-InspX service when problems occur
  • Insight into operational performance bottlenecks
  • Automatic archiving and classification of reject images
  • Optional archiving of all inspection images
Simultaneous Underfill and Overfill Monitoring

The FillTrac can simultaneously measure underfill and overfill levels.

Filler Monitoring

With the filler monitoring package, the Solo can track the performance of each filler valve in the filler and report out detailed statistics on its filling performance. The Filler Monitoring package supports both beverage and food fillers.

Seamer Sampling

With the automated seamer sampling option, the Solo provides fully automated sampling at programmed intervals. The system also supports on demand sampling.

Cocked/Missing Cap Detection

The cocked/missing cap sensor is an inexpensive way to ensure that containers are properly capped.

Missing Foil Detection

The missing Foil sensor verifies the presence of foil seals under caps.

Full Assortment of Ejection Options

Peco-InspX designs and manufactures a wide assortment of high performance ejectors and diverters. Click here for more information.
